Operation

Step 1: operate with the game machine's standard mode Normal Open

Step 2: switch to the correct speed(pulse) of coin machine: FAST 25ms.MEDIUM 45ms and SLOW 65ms

Step 3: Connecting the +12V DC and Ground wiring for the coin Acceptor.

Step 4: Arrange the token sample that you want the Coin acceptor to accept

Step 5: Set the switch from "Start" to "Set" position.the LED light will show "00".press the switch which for adjusting the coin's value.to adjust the coin value when the coin programming."00-99" means how many times of the out ,pulse signal will be sent when the programmed coin was deposited.return the switch from "Set" to "Start".it is finished

Step 6: Set the switch from "NOM" to "MGN" position.then turn the switch from "Start" to "Set" position.the LED show default "P1"."P1-P9" means a output signal needs how many programmed coins to be deposited like "P1.P2.P3…P9"

Step 7: Prepare the needed sample coins.

Step 8: Insert 10pcs coins in turn to set the coin (time interval 0.3 seconds)

Step 9: Turn the coin set switch to "Start" and finished the setting.

Apply to: vending machine, wash machine, game machine, shoe cleaning machine, TV, Massage chair, petrol filling station, automatic battery recharge, PC.etc.
